Camera Pravis PNC-SD300
Xem ảnh lớn

Camera Pravis PNC-SD300

FEATURE : • 1/2.8" 2MP PS Exmor IMX122 CMOS Sensor • 1920(H) x 1080(V) • Real-time High Definition Speed Dome Camera • Triple codec, Simultaneous Multi-Streaming • Local SD Card Backup • 360x Zoom Control (Optical 30x, Digital 12x) • Endless 360° Pan Rotation • Day & Night (ICR) • 1024 Preset, 128 Pattern, 128 Scan and 128 Group Functions • IP66 environment protection as well as built-in Fan & Heater 'IP ZOME' • Vandal-Proof (Dome Cover: PC / Housing & Accessories: AL Die-cast) • Built-in Fan & Heater • Virtual Joystick on the Image

Hãng sản xuất : Pravis - Hàn Quốc
Khuyến mại :
Bảo hành : 36 tháng
Địa điểm bán : Toàn Quốc

Đánh giá : 0 điểm 1 2 3 4 5

Chia sẻ :
MODEL               PNC-SD300
Camera
Image Sensor 1/ 2.8 Progressive CMOS
Total pixels 2.0 Mega Pixels, (Max. Image Resolution : 1920x1080)
Min. illumination Color: 1.7 Lux @50IRE, F1.6 ; B/W: 0.3Lux @50IRE, F1.6
Digital Shutter Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)
Lens
Focal Length 4.6~138.0mm, F 1.6~F4.7
Max. Aperture Ratio F1.6(Wide) / F4.4(Tele)
Angular Field of View H : 62.8˚(Wide) ~ 2.23˚(Tele) / V : 36.8˚(Wide) ~ 1.26˚(Tele)
Min. object distance Wide : 1.4m (4.59ft), Tele : 1.9m (6.23ft)
Focus Control Auto / Manual / One push
Lens / Mount Type DC auto iris / Board-in type
Video
Compression H.264 (MPEG-4 part 10 / AVC), MJPEG
Resolution Max. 1920 x 1080
Video output CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
Frame Rate H.264 : Max. 60fps at all resolutions
MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps
S / N Ratio 50dB
Streaming  Capability Multiple streaming (Up to 10 profiles)
Video Quality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Audio
Audio in Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ω
Audio out Line out (3.5mm mono jack), Max output level : 1 V rms
Audio Compression Format G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,
G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio  Communication Bi-directional audio
Network
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP,
IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
IP IPv4, IPv6
Security HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
Streaming  Method Unicast / Multicast
Max. User Access 15 users at unicast mode
Edge Storage SD/SDHC/SDXC
Compliance ONVIF profile S, SUNAPI (HTTP API), SVNP 1.2
LAN 1 RJ45 (10/100BASE-T)
Smart Codec Manual mode (Area-based : 5ea), Face detection mode
Webpage Language Mutil. Languages
Web Viewer Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 / 10.8
Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19),
Google Chrome (Ver. 15 ~ 32), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 Only), 5.1.7)
Central  Management Software SmartViewer, CSM
Mobile phone For iOS, Android
Operation
Camera Title Off / On (Displayed up to 15 characters)
Day & Night Auto (ICR) / Color / B/W
Backlight  Compensation Off / BLC / HLC
Wide dynamic Range 120dB
Contrast  enhancement PSDR (Pravis Super Dynamic Range) (Off / On)
Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
Digital image Stabilization Off / On
Defog Off / Auto / Manual
Motion detection Off / On (4ea rectangle zone)
Privacy Masking Off / On (32 zones of rectangle zone)
Gain Control Off / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Zoom Digital 12x / Optical 30x
Flip / Mirror Off / On
intelligent Video Analytics Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection
Alarm in Input 4
Alarm out Output 2 (Relay)
Remote Control interface RS-485
RS-485 Protocol Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, Bosch, GE
Alarm Triggers Motion detection, Tampering, Audio detection, Face detection, Video analytics, Alarm input,Network disconnection
Alarm Events File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP, Local storage (SD/SDHC/ SDXC) or NAS recording
at network disconnected & event (Alarm triggers), External output
Mechanical
Pan / Tilt Range 360˚ Endless / 210˚ (-15˚ ~195˚ )
Pan / Tilt Speed Preset : 700˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Preset / Preset Accuracy 255ea / ±0.2˚
Auto Tracking Off / On
General
Operating Humidity 0% - 90%
Operating Temperature 24V AC : -50°C ~ +55°C (-58°F ~ +131°F) /  PoE+ : -30°C ~ +55°C (-22°F ~ +131°F)
Power AC 24V [ Heater : O‑ 23W / On 55W ] , High-PoE IEEE 802.3at(40W)
Protection Level IP66
Colors White
