Model

UV820-USB3.0

 Sensor

1/2.8 inch high quality HD CMOS sensor

 Pixels

Dynamic image:  16: 9   2,070,000 effective pixel

  Static image :   16: 9   2,100,000 effective pixel

 Video signal

1080P60/50/30/25, 720P60/50/30/25

Zoom

18x optical zoom,  f＝4.7---84.6mm

View angle

3.2°（far）--62°（near）

Minimum lux

1.8Lux

White balance

Auto/ Manual

Focus

Auto/ Manual

Iris

Auto/ Manual

Electronic shutter

Auto/ Manual

BLC

Open/close

S/R

>50dB

Input / Output interface

HD interface

USB3.0 and DVI-I interface

Control interface

8 pin mini DIN

Control Signal Format

Start bit: 1;  Data bit: 8; Stop bit: 1;  Baud Rate: 9600/4800/2400bps

Power supply Interface

HEC3800 power jack

General specification

Mechanism

Rotation

Pan rotation: ±170°     Tilt rotation: -30 °～+90°

Manual control speed

Pan: 0.1-150°/sec    Tilt: 0.1-80°/sec

Preset control speed

Pan: 40°/sec;       Tilt: 30°/sec

Color

                                     Black /Silver grey

Power Supply Adapter

AC110V-AC220V  to  DC12V/1.5A

Input voltage

DC12V(DC11.5-DC12.5V)

consumption

10W(max)

Store temperature

-10℃  to  +60℃

Working temperature

0℃  to  +45℃

Dimension （W x H x W）

265mm×144mm ×171mm

Weight

1.9KG

Application

For indoor use
